AC load bank

FEATURES

Capability to operate on three-phase and single-phase networks
Suitable dimensions with easy portability
Capability to operate on DC voltage
Capability to be paralleled to increase capacity

APPLICATIONS

Testing and commissioning of generators and UPS systems
Real-world load simulation for solar and wind systems
Calibration and troubleshooting of power systems
Simulation of complex loads in research systems

Virtual AC load bank model PAL-3Ph-100kW, very suitable for testing and commissioning diesel generators and high-power UPS systems. This system has a resistive load with a maximum of 100 kW and can be connected to single-phase or three-phase networks. Its small size and weight make it easy to transport. The system can be used manually in two modes.

MODEL ENCODING

ACAC load

-

3PH3-phase

-

100KWPower

Model

3PH-100KW

Electrical Ratings

Main Input Voltage

240/400 VAC, 3-phase, 50 Hz

Power Rating

100 kW

Auxiliary Power Supply

220 V, 1-phase, 50 Hz

Cooling System

Type

Forced air cooling

Load Steps

Steps

2, 3, 5, 20, 20, 50 kW

Mechanical Specifications

Dimensions (W × D × H)

46 × 100 × 93 cm

Weight

80 kg

Monitoring Features

Electrical Parameters

Total Power, Voltage, Current, Frequency

Safety and Protection

Input Protection

Main circuit breaker (250 A, 3-phase)

Branch Protection

Fuse protection for each load branch

Fan Protection

Fault detection via airflow detector
